Re: DIY Fitting of Heated Seats... [Re: flyfisher] #768953
08/02/23 11:00 PM
08/02/23 11:00 PM
Joined: Mar 2009
Posts: 3,293
N
nick w Offline
Talk Morgan Addict
nick w  Offline
Talk Morgan Addict
N

Joined: Mar 2009
Posts: 3,293
At my local Aldi you can buy a heated seat thing which plugs into a lighter socket. I bought one for my mg. £8.95. works brilliantly, takes 30 seconds to fit.
Haven't tried it in the mog as the heater is so good.

Last edited by nick w; 08/02/23 11:14 PM.
Re: DIY Fitting of Heated Seats... [Re: flyfisher] #768961
09/02/23 06:37 AM
09/02/23 06:37 AM
Joined: Nov 2018
Posts: 5,126
Northants, UK
TBM Offline
Charter Member
TBM  Offline
Charter Member

Joined: Nov 2018
Posts: 5,126
Northants, UK
Had a set put in when I had my seats retrimmed - there were about £40 from eBay.

I have an old trad, so I made some brackets and fitted the switches either side of the heater I also fitted myself.

[Linked Image]


1972 4/4 4 seater - 3G Morganeer
1981 MGB GT
Too many ratty motorbikes
Re: DIY Fitting of Heated Seats... [Re: TBM] #769019
09/02/23 07:17 PM
09/02/23 07:17 PM
Joined: Nov 2015
Posts: 6,015
People's Republic of South Yor...
CooperMan Offline
Just barreling along
CooperMan  Offline
Just barreling along
Talk Morgan Sage

Joined: Nov 2015
Posts: 6,015
People's Republic of South Yor...
Originally Posted by TBM
Had a set put in when I had my seats retrimmed - there were about £40 from eBay.

I have an old trad, so I made some brackets and fitted the switches either side of the heater I also fitted myself.

[Linked Image]

Very neat thumbs


Jon M
Re: DIY Fitting of Heated Seats... [Re: flyfisher] #769479
17/02/23 04:52 PM
17/02/23 04:52 PM
Joined: Aug 2006
Posts: 863
Perthshire & Kent
F
flyfisher Offline OP
Talk Morgan Regular
flyfisher  Offline OP
Talk Morgan Regular
F

Joined: Aug 2006
Posts: 863
Perthshire & Kent
Many thanks for your tips and advice, I have fitted the pads to one seat, I had to remove some c clips to get the cover off slightly so I could get the pad in place. it’s the tombstone recliner so might be different for others.

Now just needs to wire it in. Any recommendations for a easy switched supply one could piggy back off?

Many thanks,
Will

Re: DIY Fitting of Heated Seats... [Re: flyfisher] #769490
17/02/23 08:42 PM
17/02/23 08:42 PM
Joined: Nov 2015
Posts: 6,015
People's Republic of South Yor...
CooperMan Offline
Just barreling along
CooperMan  Offline
Just barreling along
Talk Morgan Sage

Joined: Nov 2015
Posts: 6,015
People's Republic of South Yor...
Originally Posted by flyfisher
Many thanks for your tips and advice, I have fitted the pads to one seat, I had to remove some c clips to get the cover off slightly so I could get the pad in place. it’s the tombstone recliner so might be different for others.

Now just needs to wire it in. Any recommendations for a easy switched supply one could piggy back off?

Many thanks,
Will

Will, which model & year ?


Jon M
Re: DIY Fitting of Heated Seats... [Re: flyfisher] #769491
17/02/23 08:52 PM
17/02/23 08:52 PM
Joined: Aug 2006
Posts: 863
Perthshire & Kent
F
flyfisher Offline OP
Talk Morgan Regular
flyfisher  Offline OP
Talk Morgan Regular
F

Joined: Aug 2006
Posts: 863
Perthshire & Kent
1995 +4

Many thanks
Will

Re: DIY Fitting of Heated Seats... [Re: flyfisher] #769496
17/02/23 09:51 PM
17/02/23 09:51 PM
Joined: Feb 2016
Posts: 6,100
East Harling, Norfolk UK
RichardV6 Offline
Talk Morgan Sage
RichardV6  Offline
Talk Morgan Sage

Joined: Feb 2016
Posts: 6,100
East Harling, Norfolk UK
Try any green wire from the fuse box. Most if not all are fed by the ignition switch. I believe fuse 15 feeds the heater fan switch on such a green wire and may be convenient. What ever fused circuit you use, ensure the rating is upped to cover the extra load. I don't think the seat pads take much so an extra 5 amps on fuse rating should suffice.


Richard

2018 Roadster - Red/Magnolia - Morton
1966 Land Rover S2a 88 - Lenny
1945 Moto Guzzi Airone
Re: DIY Fitting of Heated Seats... [Re: flyfisher] #769502
17/02/23 11:20 PM
17/02/23 11:20 PM
Joined: Jan 2021
Posts: 20
Germany-Sauerland
GBpluseight Offline
New to Talk Morgan
GBpluseight  Offline
New to Talk Morgan

Joined: Jan 2021
Posts: 20
Germany-Sauerland
Hello Will,
I have retrofitted heated seats in a 93 plus8. Some fuses have battery voltage, others have ignition voltage. So be careful! I used Lucas 2-stage toggle switches and switched the battery voltage via a relay. If you want, send me your mobile number personally, then we can call via WhatsApp.
Greetings from Germany
G√ľnter

Sorry for my bad English but school is out since many years


Life is too short to drive boring cars!
Re: DIY Fitting of Heated Seats... [Re: flyfisher] #769584
18/02/23 08:34 PM
18/02/23 08:34 PM
Joined: Aug 2006
Posts: 863
Perthshire & Kent
F
flyfisher Offline OP
Talk Morgan Regular
flyfisher  Offline OP
Talk Morgan Regular
F

Joined: Aug 2006
Posts: 863
Perthshire & Kent
G√ľnter, many thanks Will PM you.

I have taken a feed off the Green / Slate wire from the heater switch so the heated seats go on / off with the heater. Which makes it convenient, my only thought is there being enough power for both..

Re: DIY Fitting of Heated Seats... [Re: flyfisher] #769928
24/02/23 09:59 AM
24/02/23 09:59 AM
Joined: Feb 2007
Posts: 475
Lincolnshire
Guten Offline
Learner Plates Off!
Guten  Offline
Learner Plates Off!

Joined: Feb 2007
Posts: 475
Lincolnshire
Received my pads yesterday. Thought I may as well fit them because I new I'd have to remove the seats to get the tunnel off to renew the rotoflex coupling, will do the webbing at the same time.
A quick check of the wiring diagram shows the switched feeds are white and green or white on my car so will use one of those to control a relay with power coming from a suitable supply, maybe the 50a circuit to a new auxy fuse box.


Simon
2002 4/4
1936 Austin 12 light 4 Ascot saloon
2018 AMG Mercedes C Class estate
2021 Audi A1 sport
